DMX 512 RGB LED Controllers
1PCS
MOQ
negotiate
Price
DMX 512 RGB LED Controllers
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Guangdong,China
Brand Name: XINHE
Certification: CE ROHS
Model Number: T-1000S
High Light:

led lights control

,

programmable rgb led controlle

Payment & Shipping Terms
Delivery Time: 13-5 working days
Payment Terms: T/T In advance,Western Union,Paypal,LC
Supply Ability: 10,000PCS
Specifications
Product Description

DMX 512 RGB LED Controllers


SD Card Controller RGB LED Controller
Quick Detail:

1, 32—256 Gray,Support software Gamma correction.
2, Support the rules and special-shaped handle.
3, Single-port output,can support 2048 lights.
4, Off-line(SD Card) control, play back content stored in the SD card.
5, T-1000S store a maximum of 16 programs,copy multiple files to the SD card in order,
after formatting the SD card as “FAT” format.
6, The program must be named in orders . Ex. :00_1.led, 01_1.led, 02_1.led.
7, Compatible with single line or double line chips.


Description:

Definition of buttons:

Buttons Meaning
SET Save Settings ( to save current settings file and the playback speed ).
MODE Change programs
SPEED+ Speed up Press speed+ and speed- on the same time the program will play circularly.
SPEED- Speed down



DC5V +5V power input
GND Power GND input
75-24V +7.5-24V power input
POWER Power indicator
ERROR Error indicator
SD CARD SD card slot



TTL signal(245/spi signal): RS485 signal.

CLK Clock signal B Signal A / DMX+
DAT Data signal A Signal B / DMX-
GND Signal ground GND Signal ground





Applications:

Support IC model

IC model Control mode for software Pixels(MAX) Note
LPD6803,D705,1101,6909, 6912 T-1000-6803 2048 pixels
LPD8806,LPD8809 T-1000-8806 2048 pixels
TM1803,TM1804,TM1809,TM1812 T-1000-TM 2048 pixels TM1804 and TM1809 are divided into high and low
TM1903,TM1904,TM1909,TM1912 T-1000-TM19 2048 pixels
UCS6909,UCS6912,UCS7009,UCS5903 T-1000-UCS-32 2048 pixels
UCS1903,UCS1909,UCS1912 T-1000-UCS-256 2048 pixels 1903 and 1909 are divided into high and low
UCS3903 T-1000-UCS-1024 2048 pixels
DMX512 T-1000-DMX 170/512 pixels Compatible with standard DMX512
WS2801,WS2803 T-1000-WS 2048 pixels
WS2811 T-1000-WS2811 2048 pixels WS2811 be divided into high and low
DS189 T-1000-DS189 2048 pixels
TLS3001,TLS3002,TLS3008 T-1000-TLS * pixels
P9813 T-1000-P9813 2048 pixels
SM16715 T-1000-SM16715 2048 pixels SM16715 be divided into high and low
SM16716 T-1000-SM16716 2048 pixels
BS0901,BS0902 T-1000-0901 2048 pixels
BS0815 T-1000-0815 2048 pixels



Specifications :

Memory card:
type: SD card(suggest using high-speed SD card)
Capacity: 128MB—2GB
Format: FAT
Store file: *.led
Physical parameters:
Working temperature : -30℃—85℃
Working voltage: DC5V / DC7.5-24V
Working power: 1W
size: L165mm×W80mm×H30mm
weight: 0.35KG
signal port: 3pin connect port




Competitive advantages:

  1. We have more than 7 years’ experience ,
  2. We have more than 20 foreign customers Who have kept purchasing from our company more than 3 years.
  3. Compared to our factories,same price,we have the better quality;same quality,we have the cheaper price.
  4. Small MOQ, Short delivery time,2 years’ warranty.
