110V 220V AC LED Driver Power Supply with 12V DC Output and 200W-250W Power Dissipation for Commercial LED Light
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| DC Output Voltage | 12V | Input Voltage | AC 170-265V |
|---|---|---|---|
| Chip Material | InGaN,AlGaInP,GaP,Epistar,5050 Rgbw Led | Working Temperature And Humidity | -30~+50 Centigrades 20-99% RH Non-condensing(waterproof) |
| Dimension | 225mm*53mm*19mm | Power Dissipation | 200W-250W |
| Luminous Flux(lm) | 150lm,60-66lm,2805-2992LM,900~1000Lm /1100~1200Lm,155 | Storage Temperature(℃) | -40 - 60,-25 - 60,-40 - 80,-30 - 60,-20 - 60 |
| Operating Temperature(℃) | -20 - 60,-40 - 60,-20 - 50,-20 - 45,-40 - 50 | Warranty | 2 Years |
| Application | Advertising Channel Letter,etc,Light Box Back Lighting,office,Decorative Lighting | Voltage | DC 12V,DC12V,DC5V/DV12V/DC24V,Ac85-265V |
| Product Name | Injection Led Power Supply | Ip Grade | IP67 Waterproof Led Power Supply |
| Highlight | 110V 220V AC LED Driver,12V DC Output LED Power Supply,200W-250W Power Dissipation LED Driver |
||
Product Description
High Energy Efficiency Strong Adaptability 110V/220V AC LED Driver Power Supply IP67 Waterproof
Product Overview
Professional IP67 waterproof LED driver power supply with high energy efficiency and strong adaptability for commercial LED lighting applications.
Key Specifications
- Place of Origin: Guangdong, China
- Brand: MIRACLE BEAN
- Certifications: CE/FCC/RoHS compliant
- Model: XH-12/24V 200/250W series
- Waterproof Rating: IP67
- Operating Temperature: -20°C to +60°C
- Lifespan: 30,000 hours
- Material: Aluminum housing with cables
Technical Specifications
| Parameter | XH-200W-B | XH-250W-B |
|---|---|---|
| DC Output Voltage | 12V | 24V |
| Rated Output Current | 33.3A | 16.6A |
| Output Power | 200W | 250W |
| Efficiency | 92% | 93% |
| Input Voltage | AC 170-265V | |
| Dimensions | 225mm × 53mm × 19mm | |
| Weight | 0.4kg | |
Protection Features
- Short Circuit Protection (auto-recovery after fault removal)
- Overload Protection
- Overtemperature Protection (shutdown with manual restart)
LED Driver Functions
- Voltage Conversion: Converts AC to required DC voltage
- Current Regulation: Maintains optimal current flow
- Overvoltage/Undervoltage Protection: Safeguards against power fluctuations
- Dimming Capabilities: Supports advanced lighting control
Ordering Information
- Minimum Order Quantity: 50 pieces
- Price: Negotiable
- Packaging: Carton or wooden case
- Delivery Time: 5-15 days
- Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
- Monthly Capacity: 50,000 pieces
Our Services
- 24-hour response time
- English-speaking support
- OEM & ODM services available
- Distributorship opportunities
- Sales area protection
- Lifelong warranty
- Comprehensive after-sales support including installation guidance
Applications
Ideal for commercial LED lighting applications including:
- Retail displays and signage
- Office and architectural lighting
- Outdoor and street lighting
- Industrial high-bay fixtures
- Horticultural lighting systems
Company Information
Shenzhen Xinhe Lighting Optoelectronics Co., Ltd. specializes in semiconductor illumination products, integrating design, development, manufacturing, and sales. With advanced technology and efficient management, we focus on LED applications for advertising and lighting sectors.
